Preliminary observations of the pygidial gland of the Bombardier Beetle, Brachinus sp.

by Mark H. Armitage and Luke Mullisen

Summary

The Bombardier Beetle (Brachinus sp, Metrius sp., Stenaptinus sp.) has been the subject of much discussion by creationists and evolutionists alike. Recent reports demonstrate the sophistication and accuracy with which these carabid beetles deliver a spray of hot quinones and steam to ward off predators. Workers over the last 40 years have reported on the histology and ultrastructure of the pygidial gland and accessory components of these defensive organs. Those reports differ significantly from the present paper. Thus it appears that some distinction exists in the morphology of the enzyme secretion bodies, the chemical reservoirs, the reaction chambers and the actual aiming nozzles of the spray systems within the family Carabidae, even though these beetles use these glands for the same purpose. In this study the pygidial gland and nozzle of one species of Bombardier Beetle is studied under light and electron microscopy (SEM and TEM) and are shown to be quite complex. This complexity could suggest an origin by design.

The Bombardier Beetle has been a subject of interest for many years. This beetle is called a ‘bombardier’ because it ejects (with an audible popping sound), a hot, highly noxious spray of aqueous benzoquinones, oxygen and steam as a defence mechanism against would-be predators.1–15 This secretion is very accurately delivered via twin sets of spray nozzles located at the tip of the beetle abdomen and is most effective at stunning predators,5 even mammals such as mice, thus allowing the beetle to escape.

Bombardier Beetles range in size from 2.0 mm overall length (Mastax) to 30 mm in length (Aptinomorphus) and can be found all over the world, from the United States and Mexico to Australia.16 They live under rocks or pebbles in cool, sandy soil, usually near a stream or a lake. Aggregating in groups during the daytime, they are usually active at night.

There exist several different types of Bombardier Beetles, which employ slightly different types of defensive structures and chemistry but generally the same method of defence—shooting at predators when threatened and then running away. One tribe, however, (Mystropomini), is known to bury itself halfway in the ground with only its abdominal tip protruding above the ground.10 Most Bombardier Beetles exist in the family Carabidae, and within that family are three subfamilies: Brachinae, Metriinae, and Paussinae.2

An early-recorded observation of these beetles was made in 1839, by the entomologist O.J. Westwood, who quoted a traveler returning from South America. He wrote that large beetles of the genus Brachinus ‘on being seized … immediately … play off their artillery, burning … the flesh to such a degree, that only a few specimens (can) be captured with the naked hand.’1

Most noticeable, is the force of the spray, which is ejected during the reaction. Some workers17 have found that the spray is ejected in explosive discharges of about 500 pulses per second, which can surprise and deter large vertebrates (even frogs),1,3,5,6,17,18 and can even send some attackers into seizures.5

One study records the velocity of the spray to be within a range of 325 to a stunning 1950 cm/s.17

Additionally, the beetle’s spray is astonishingly hot (some are unleashed at 100°C), a feature that seems to be dependent on the biochemistry of the reaction between the hydroquinones, hydrogen peroxides and the catalases and peroxidases that the beetle synthesizes and stores in separate reservoirs.1,2,6,9,11,13,17,19

Pygidial Gland

Figure 1. Pygidial gland and accessory components of the Bombardier Beetle defence system (after Forsyth).12 Scale bar = 1.0 mm.

The structure of the defence system of the Bombardier Beetle, as reported in the literature, is complex, consisting of two sets of secretary lobes, collecting canals, collecting reservoirs, one-way valves, sphincter muscles, reaction chambers, exit tubes and exit nozzles (Figure 1).1,2,4,6,9,15,17 All known carabid ‘Bombardier’ Beetles have similar internal structures, and they all employ a similar chemical reaction.2

The Bombardier Beetle has, in recent years, been a hot topic in the creation/evolution debate. It has been argued by creationists that the beetle serves as an excellent example of the kind of design that could not have formed through slow, random genetic mutations over time.20–27 Behe, however, maintains that ‘Darwinian evolution might have occurred’ to produce these defensive anatomical features,33 but he is also quick to point out that nothing has truly been explained by this type of evolutionary story. This argument is hotly contested by evolutionists who state that it is quite probable that the pygidial defence system of the Bombardier Beetle evolved over time through natural selection. 17,28–32

The defence system of the Bombardier Beetle is very complex and no one has attempted to truly explain the design or intrabaraminic diversity of the system. This paper serves as a preliminary report on observations of beetles from the Brachinus genus.

Structure

According to the literature, paired secretory lobes connect via long tubes to collecting reservoirs, each of which are surrounded by a thin layer of muscle, and joined to a reaction chamber by means of a one-way valve controlled by a sphincter muscle.1,4,6,15 One study,17 however suggests that the valve itself oscillates passively, in an automatic fashion. That report maintains that the collection reservoir, the valve, and the reaction chamber function together to work as a ‘pulse jet,’ with the spray emitted in pulses. Using a microphone, force transducer (piezoelectric crystal), and high-speed cinematography, workers discovered that each discharge (lasting 2.6 to 24.1 ms) consists of 2 to 12 individual pulses, and that they are in reality individual micro-explosions repeating at 368 to 735 pulses per second within the reaction chamber.17 These researchers postulate that the beetle does not squeeze the collection reservoir or the sphincter muscle rapidly, but that the beetle applies even, steady pressure on the collection reservoir. Once the muscles around the reservoir squeeze the first amount of reactants through the valve into the reaction chamber, the resulting explosion causes the pressure to rise rapidly in the reaction chamber, forcing shut the one-way valve. The products of the reaction then exit the chamber with a pop and a puff, and the pressure inside the reaction chamber lowers again, falling below the pressure of the collection reservoir, which is still being squeezed by the reservoir muscles. The cycle then repeats itself—the valve thus oscillates passively.

The secretory lobes secrete aqueous hydrogen peroxide and hydroquinones, which are stored in large quantity in the collecting reservoirs. It is reported that the same cells actually synthesize and separate both the hydrogen peroxide and the hydroquinones.15 The stored liquids remain in the full reservoirs until needed. When the Bombardier Beetle is threatened (such as with a bite on the limb) it contracts its collection reservoirs, moving the hydrogen peroxide and hydroquinones into the reaction chamber through the valves. The reaction chamber is said to be lined with enzyme-secreting structures which produce peroxidases and catylases,1,4,15 although some studies state that oxidases and other enzymes are secreted and stored in the reaction chamber.6,17

When the hydrogen peroxide and hydroquinones come into contact with the enzymes, an explosive reaction takes place, yielding water, quinones, heat and gaseous oxygen. The pressure of the free oxygen propels the mixture out of the reaction chamber through the spray nozzle, directed to the target (either at the predator or on the beetle’s own integument as a protective measure) by way of flanges (as in the tribe Paussini), line grooves (as in the Metriini), or spray deflectors (as in the Brachinini).

The overall structure of the secretory lobes and collecting canals is said to resemble a cluster of grapes,12 the stalk being the final collecting canal leading to the collecting reservoir. These authors state that each lobe is essentially a ball of cells which all face inward, aligned radially around a central collecting lumen (in the tribes Brachinini and Paussini, where secretory lobes are fingerlike, the collecting lumen is long and extends the length of the lobe).9 Each secretory cell has an elongate secretory vesicle which is almost as long as the cell itself and is centrally located with a ‘coated membrane’ crowded with microvilli.15 An efferent cuticular tubule, or duct, leads out of the end of the vesicle towards the center of the secretory lobe. The duct extends past the end of the cell, and through a duct-carrying cell. A duct-carrying cell surrounds the duct, having its plasma membrane between it and the duct, which in turn is surrounded by its own vesicular membrane. Finally, the duct terminates into the central collecting lumen in the middle of the secretory lobe. Subsequent to the collecting lumen, the secretion travels through the collecting canal to the ‘stalk,’ or the main collecting canal of the ‘grape bunch,’ which will then take the secretion to the collecting reservoir.12

Bombardier Beetles in general have similar collecting canals, however there are some differences. The Ozaenini and Paussini tribes have identical collecting canals, and this supports the widely accepted theory that the Paussini have developed from the Ozaenini, but it is agreed that these are not directly related to the Brachinae.6,9 Other authors lament the close similarities in defensive systems in very disparate organisms. In fact the chemical secretions of the Brachinae ‘bear a close resemblance to those of certain … millipedes … earwigs and cockroaches.’5 Thus evolutionists are faced with the vexing conundrum that this defence system evolved independently in separate groups.2,4,5,9,11 These evolutionists might state that ‘convergent evolution’ was responsible for this, but that simply does not address the question.

Metriini, a Bombardier Beetle that has a different method of spraying its secretion, has dissimilar glands in most aspects to the Ozaenini, but the collecting canals of Metrius, a well-known genus in Metriini, are very similar to both the Ozaenini and Paussini.12 The Brachinini have exceptionally long collecting canals, up to twice the length of the body of the entire beetle, seemingly much longer than would be necessary to move the secretion from the lobes to the collecting reservoir,12 and again, confusing the systematists.

Abdomen

Figure 2. Brachinus abdomen, LS. Light micrograph showing paired secretion lobes (1 arrow), paired storage reservoirs (2 arrows), paired reaction chambers (RC), deflection paddle (Pad). Scale bar = 1.0 mm. [Click image to enlarge.]

Secretory Lobe

Figure 3. Light micrograph showing secretory lobe, preserved secretions (Sec). Scale bar = 0.5 mm. [Click image to enlarge.]

Inner Secretory Lobe Walls

Figure 4. TEM micrograph showing chitinized inner secretory lobe walls (black arrows). Scale bar = 5.0 mm. [Click image to enlarge.]

Chitinized Walls

Figure 5. TEM micrograph showing chitinized walls (black arrows) and heavy population of mitochondria (white arrows). Scale bar = 1.0 m. [Click image to enlarge.]

Dividing Bacteria

Figure 6. TEM micrograph showing dividing bacteria within secretory lobes. Scale bar = 1.0 m. [Click image to enlarge.]

Secretory Lobes

Figure 7. TEM micrograph showing fine structure of chitinized layer and dividing bacteria within secretory lobes. Scale bar = 1.0 m. [Click image to enlarge.]

Storage Reservoir

Figure 8. Light micrograph of storage reservoir surrounded by massive muscle layer. Scale bar = 1.0 mm. [Click image to enlarge.]

Striated Muscle

Figure 9. TEM micrograph of striated muscle (black arrows) around secretory lobe. Scale bar = 1.0 m. [Click image to enlarge.]

Collecting Tube

Figure 10. TEM micrograph of striated muscle (black arrows) around collecting tube. Scale bar = 1.0 m. [Click image to enlarge.]

Collecting Stalk and Reservoir

Figure 11. Light micrograph of striated muscle circumscribing juncture between collecting stalk and reservoir. Scale bar = 0.5 mm. [Click image to enlarge.]

Passageway out of Reaction Chamber

Figure 12. Light micrograph of striated muscle surrounding passageway out of reaction chamber. Scale bar = 1.0 mm. [Click image to enlarge.]

Abdomen Tip and Deflection Paddle

Figure 13. Light micrograph of heavily muscled abdomen tip and deflection paddle (black arrows). Scale bar = 0.75 mm. [Click image to enlarge.]

Fat Bodies with Lipid Drops

Figure 14. Light micrograph of fat bodies filled with lipid drops (black arrows). Scale bar = 0.5 mm. [Click image to enlarge.]

Spray Nozzles

Figure 15. SEM micrograph of abdomen tip with paired spray nozzles (white arrows) and paddles (Pad). Scale bar = 1.0 mm. [Click image to enlarge.]

Flattened Papillae

Figure 16. SEM micrograph; close-up of one spray nozzle showing paired flattened papillae (black arrows). Scale bar = 0.2 mm. [Click image to enlarge.]

Spray Nozzle Pores

Figure 17. SEM micrograph; close-up of spray nozzle showing nozzle pores. Scale bar = 0.2 mm. [Click image to enlarge.]

Everted Female Spermatheca

Figure 18. SEM micrograph showing everted female spermatheca. Scale bar = 1.0 mm. [Click image to enlarge.]

The collecting reservoir varies in shape and size among Bombardier Beetles. Covered in a thin muscle layer, and having both an efferent duct opening and an opening valve, differences can be seen between the different tribes of Brachinini, Metriini and Paussini.9,12 The reaction chamber, as mentioned, is confusingly reported on the one hand to store secretions of enzymes, and on the other to secrete them in real time when the beetle is alarmed.

Once the hot gaseous spray exits the reaction chamber, it travels through what Forsyth12 calls a ‘gaping aperture,’ at the ninth tergite (a plate of abdominal cuticle), the characteristics of which vary with the different kinds of Bombardier Beetles. In the Ozaenini and Paussini it lies on the posterior wall of the reaction chamber, ‘but in the Brachinini the latter opens to the outside via a short membranous tube.’12 The results of the present study show that this structure is far from merely a ‘short membranous tube.’

Additionally, the Bombardier Beetle has the ability to direct its defensive spray toward its aggressor with pinpoint accuracy. Several Bombardier Beetles (most notably Brachinini) show the ability to direct their deterrent spray in almost any direction, accurately enough to target not only different limbs (what the aggressor usually bites or grasps), but different leg segments of the same limb.6,8,17 Others in the subfamily Paussini employ a different method of directional control, using flanges on the integument of the beetle to guide the spray to the desired location.2,4 Still others (Metriini) use lined grooves to conduct a hot quinoid foam to the area of the body being attacked.9

The flexible abdominal tip of the genus Brachinus can bend around in all directions even shooting directly forward, in an anterior direction over the dorsal surface, with help from special deflection plates.8,17 These hardened cuticular plates, acting as deflectors, are located just outside the opening of the reaction chamber, and give directional control to the discharge by changing their angle of deflection. Exactly how these deflectors are used to direct the spray is not understood.

The Paussini and Ozaenini, of the subfamily Paussinae, also direct their spray effectively, but employ a different method of targeting. Using flanges (‘curved, fluid directing devices that serve as launching guides for the anteriorly aimed discharges’),7 these beetles can slingshot the liquid around the outside of their integument, guiding the steaming liquid in a variety of directions. Eisner and Aneshansley show that this slingshot method is in reality caused by the Coandă effect—the propensity of liquids or gases to flow along a curved surface, adhering to them as they move.7 The Paussini use this effectively, as their special flanges allow them to discharge forward past their head, although it is not as precise as the Brachinini spray. Considered by many to be more primitive than the other Bombardier Beetles,9 the subfamily Metriinae shoots its quinoid mixture as a puff of noxious vapor and hot foam at 55°C. Although it cannot spray it, this beetle can direct the foam to various locations on its integument, effectively deterring predators.2

The spray of beetles in the tribe Brachinini, has been shown to deter several natural predators.4–6,8 These include the ant Pogonomyrmex badius, which ‘retreated swiftly,’ and commenced to have a series of ‘short, intermittent seizures, abrupt in onset, during which the legs stretched outward and flailed ineffectually against the substratum, greatly hampering and often completely stalling forward movement.’5

Also observed to be deterred was the beetle Galerita janus, which when sprayed, fled ‘hastily for a few centimeters, it suddenly became sluggish and circled aimlessly … .’5 In addition, the spray was also effective against the praying mantid, Hierodula patellifera and the spider, Lycosa helluo which was ‘brought to a sudden halt.’

Few ultrastructural studies of the pygidial gland and the spray nozzle of the Bombardier Beetle have been attempted. In fact only one extensive fine structure report can be found in the literature15 in which the secretion lobes, storage receptacles, and reaction chambers have been examined and under light and transmission electron microscopy and photographs published. Some reports are accompanied by limited scanning electron micrographs8,9,17 or photographs through a dissecting microscope.9 Most reports, however,1,2,4,6,17 are simply accompanied by a copy of a drawing made by workers in 1961,13 or a variation of that same drawing. This includes reports in the creationist literature, most notably the treatment by Michael Behe.33

Materials and methods

Twenty beetles of the Brachinus genus, (probably B. mexicanus and B. gebhardis) were collected by hand from underneath rocks lying along a stream bed in Santa Clarita, Los Angeles County, California. Beetles were observed to congregate in tightly knit groups until disturbed and then went scurrying in all directions. Beetles fired off their hot quinone spray when captured and left fingertips blackened by the spray. They were kept in covered 30 cm diameter glass Stenner dishes in the laboratory and were sustained by bits of chicken (lunchmeat) and water-soaked cotton swabs for over a year. Beetles calmed significantly over time in captivity to the point that they rarely fired their spray when nudged by finger, and they would often mill around when disturbed rather than run and hide.

Ten beetles were prepared for SEM by cooling on ice and immersion into cold 2% glutaraldehyde buffered in .2M sodium cacodylate for 36 hours. Abdomens of fixed material were washed in water and buffer and were passed through a graded series of acetone assisted by microwave radiation in a laboratory microwave oven (Ted Pella, Inc, Redding, CA.). Dehydrated material was left in tetramethylsilane overnight, allowed to air dry, and then was sputter coated in gold and observed on a JEOL SEM at 15kV.

Ten beetles were prepared for TEM similarly, except they were postfixed in 2% osmium, then washed and dehydrated. Complete, dehydrated abdomens were infiltrated and embedded in Epon-Spurrs resin in the microwave oven, and silver sections were collected, stained and viewed on a Zeiss 10C TEM.

Results

Secretory lobes, collecting canals, storage reservoirs, reaction chambers and muscular exit nozzles were all relatively well preserved (Figure 2), although the reservoirs often displayed incomplete Epon-Spurrs infiltration. This may possibly be a result of incomplete dehydration due to the large amounts of hydrogen peroxides and hydroquinones stored there. Secretory lobes were very well preserved, including some of the secreted material (Figure 3) and the collecting stalks and collecting lumens were clearly visible. The inner walls of the secretary lobes were thickly lined with chitinized lamella (Figures 4, 5) with a coarsely grained, undulating outer margin. Proximal to this chitinized layer was a tissue layer with large and abundant mitochondria (Figure 5). The chitinized walls that lined many of the spray flow structures exhibited birefringence in polarized light microscopy.

A stunning discovery was the presence of many rod-shaped bacteria adhering to or just adjacent to the lumen of the secretory lobes (Figures 6, 7). Bacteria were present in large numbers in that structure alone, and not in the ventriculus (or digestive structure) as expected. The ventriculus had thin layers of muscle around it, which provides light peristaltic pressure for elimination.34

Massive striated muscle was found, as anticipated, surrounding the storage reservoir (Figure 8), but unexpectedly the secretory lobes (Figure 9), collecting tubes (Figure 10) and parts of the main collecting stalk all had thick layers of muscle around them. In fact, the juncture between the main collecting stalk and the storage reservoir was collared by a ring of striated muscle (Figure 11). The reaction chamber was also surrounded by muscle, in contrast to earlier reports for other genera of these beetles. The enzyme-secreting structures, which purportedly line the reaction chamber walls, were not evident. Abundant musculature often surrounds various passageways leading from the reaction chamber to the exit nozzle, and these passageways are also very thickly lined with chitin (Figure 12). The abdomen tip was heavily muscled, as expected, and these muscles extended out to the cuticular deflector plates (Figure 13).

The spaces surrounding the reservoirs, secretion lobes, collection canals and muscle tissues were densely packed with fat bodies comprised mostly of large lipid droplets (Figure 14).

The secretory cells were accurately described by Schnepf et al.,15 complete with microvilli spanning the center of the cell.

The nozzle of Brachinus is different from any description heretofore presented in the literature on this or other genera. Extending from the abdominal tip on either side of the tip are tongue-like projections (Figure 15), which upon closer examination reveal a pattern of apertures used for spray dispersal (Figure 16). A large pore is embedded at the tip of the nozzle containing flattened hairs or papillae that extend out of the pore and above the surface of the nozzle. Additionally, five or more much smaller pores run along the midline of the tongue-like nozzle, each with a small papilla extending from the center of the pore.

Some nozzles had fewer small pores (Figure 17), but all of them had at least 3 along the midline. These nozzles could not be confused with ‘eversible gland openings,’ as described by Forsyth,12 or the obviously everted female spermatheca (Figure18).

Discussion

In contrast to previously reported structural studies of Bombardiers9,17 it is here shown that muscle surrounds all structures related to the defensive spray of the genus Brachinus, including the reaction chamber. Workers have suggested the possibility that some of these structures represent tracheoles (the finer branches of trachea or tubes through which oxygen reaches arthropod tissues), however, our EM study of these areas clearly yielded the Z-lines associated with striated muscle. Tracheoles were visible in many of the sections we made, and they look nothing like the typical muscle fibers shown in Figures 11 and 12.

According to Eisner,5 the Brachinini can fire quite rapidly (four discharges in succession) if exposed to prolonged pulling on an appendage. The total numbers of discharges, one after the other, may vary by individual beetle. Eisner writes: ‘Five specimens that had remained undisturbed for six days discharged 9, 13, 22, 23, and 29 times respectively, in periods of less than four minutes each, before their supply appeared to be exhausted.’ Eleven hours later, the same beetles were able to discharge 2, 0, 4, 5, and 4 times respectively. The muscled secretory lobes would allow the beetle to push the secretions into its collection reservoir faster, decreasing its recovery time after it had depleted its supply of secretions. The same would follow for the collection canals and storage reservoirs. Muscles around the reaction chamber may serve to exercise some control over the violence of the reaction, or to quickly expel left over byproducts in anticipation of another blast.

Additionally, the Bombardier Beetle can ‘play off its artillery’ much faster than other chemically secreting arthropods. Toads can capture such arthropods (millipedes and other beetles which secrete noxious substances) because a rapid flick of their sticky tongue allows them to grab and swallow before the arthropod can take action.35 However, Bombardier Beetles are able to discharge their spray in as little as 90 milliseconds when sufficiently provoked, thus outgunning the American toad.17 The heavily muscled secretion lobes, reservoirs and reaction chamber as shown in this study would account for this ability to exhibit speed and rapid repetition when provoked to discharge. The large fat bodies, brimming with lipids as shown in Figure 14, are closely approximated to the muscle groups. This would allow for the rapid processing of lipids for the energy needed to discharge spray repeatedly.

As mentioned, the Bombardier Beetle has particularly high accuracy for hitting its intended target. This accuracy could certainly be as a result of employing the previously described deflectors and highly flexible abdominal tip, but the muscular eversible spray nozzle with hydrodynamic vent holes as shown here would only serve to improve that accuracy. The remarkable photographic evidence of the aiming capability of Stenaptinus insignis previously reported8 shows clearly that the spray emanating from the abdominal tip of the beetle is already well dispersed and not ejected as if from a pin-point source or aperture. Thus the nozzle pores and hair-like papillae reported here must serve to disperse the spray as shown.

Design aspects

The question of the Bombardier Beetle’s origin, like many questions regarding the origin of complex structure, has had quite a history of arguments. Although it is a complex system, it can be relatively easily explained and understood by the layperson. Thus, it has become a much-used example by creationists in their argument for creation from design.20–26,33 Because the Bombardier system is widely used by creationists as an example of creation, it has been thoroughly criticized by those supporting the theory of evolution.28,29,31,32,36

Duane Gish of the Institute for Creation Research was the first to use the Bombardier Beetle’s defence system as an example of complex design,23 in an effort to show that evolution could not bring about integrated systems such as that of the Bombardier Beetle. In his book, Dinosaurs: Those Terrible Lizards,22 Gish explained the Bombardier Beetle’s defence mechanism, arguing that it could not have arisen by way of variation and natural selection. He reasoned that all the components of the mechanism would have had to be present and functioning from the start, otherwise the system would not work. This useless system would be selected against thus eliminating it from the gene pool. A worse case scenario, he reasoned, would be that the beetle’s half-evolved system would misfire, causing it to blow itself up, driving it to extinction. Gish made mention that the hydroquinones and hydrogen peroxides were ‘explosive,’ when clearly, these two compounds are not explosive when combined—they just turn brown as a result of the oxidation of the hydroquinones to quinones. The fact is, they are stored by the beetle in large quantities and yet they remain completely clear and colorless, even after the beetle has died (our personal observations).

Gish stated that there must be an ‘inhibitor’ present in the mixture, added by the beetle to prevent an explosive reaction. Gish used the word ‘explosive’ based on a translation error made by Dr Robert Kofahl on an early article published in German on the Bombardier Beetle.13,23 A correct translation might have been ‘unstable,’ according to Gish.23 Meanwhile, the evolutionists, particularly Frank Awbrey and William Thwaites23 seized upon the notion that Gish had made a mistake and publicly ridiculed him.

Weber, writing for an anti-creationist newsletter,31 pointed out that Gish had wrongly included the use of an ‘inhibitor’ and ‘anti-inhibitor’ by the beetle, stating that neither were reported by Schildknecht and Holoubek.

Other creationist writings have perpetuated the notion that these compounds ‘literally explode’ when combined24,25 but to their credit one anonymous creationist writer did report that the mixture would simply discolor and become un-reactive.20

A popular creationist book27 on the subject of the Bombardier Beetle, which continues to be printed also contains errors regarding the structure and function of this beetle. It states that ‘We have two glands in our tail ends. One makes “hydroquinone.” The other makes “hydrogen peroxide”’ (p. 23). As mentioned, it has been reported that the same secretion cells make both compounds. Additionally, several times in the creationist book text, the defensive discharge is said to be accompanied by flashes of light—something not reported anywhere in the literature nor observed during our experimentation with Bombadier Beetles over two years.

Bombardier Beetles employ a very sophisticated defence system—a compilation of distinct and separate anatomical parts, brought together into a complete, comprehensive and very effective system. The system seems to function as a designed machine by rapidly and effectively thwarting predatory behaviour. Behe has shown33 that for biochemical complexes, all the components of the complex (machine-like system) have to be present in order for the biochemical machine to do its job. He has also argued, however, that Darwinian evolution may have been responsible for the formation of the Bombardier Beetle defensive system. It may be that we are observing irreducible complexity in the defensive system of these carabid beetles, but, in order to make that claim we would have to show that all of the genes involved in forming the secretion lobes, reservoirs, oscillating valves, reaction chambers, muscles, hydrogen peroxides, hydroquinones, inhibitors and enzymes are all essential for the working Bombardier system. In addition we would have to demonstrate that the system would fail to function if one of these components were removed. If we could succeed in demonstrating this, an argument may be made that the concept of irreducible complexity applies to anatomical structures, just as they do to biochemical complexes, but such an argument is beyond the scope of this study.

The differences noted between Brachinus (this study) and other genera of Bombardier Beetles may be significant in understanding intrabaraminic diversity in this group. It is the authors intent to conduct further ultrastructural, behavioral and baraminological studies of Bombardier Beetles in the hope of understanding the diversification within these beetles.

Acknowledgements

The authors thank Todd Wood and the anonymous reviewers for constructive comments on drafts of this work. We are also indebted to Bob Jensen for assistance in collecting and in identification.


Mark Armitage studied biology and plant pathology at the University of Florida. He holds an MS in Biology with emphasis in electron microscopy from the ICR Graduate School. His photomicrographs have been featured on the covers of seven scientific journals and he has published widely on parasitology. He is enrolled in a doctoral program at Liberty University, and currently runs an electron microscopy facility in Southern California. Mark Armitage is a Life Member of the Creation Research Society. Return to top.

Luke Mullisen received his B.S. from the Biological Sciences Department, California Polytechnic State University in 2001. He has a keen interest in the Creation-evolution controversy. Return to top.


References

  1. Aneshansley, D.J., Eisner, T., Widom, J. M. and Widom, B., Biochemistry at 100°C: explosive secretory discharge of Bombardier Beetles (Brachinus), Science 165:61–63, 1969.
  2. Aneshansley, D.J., Jones, T.H., Alsop, D., Meinwald, J. and Eisner, T., Thermal concomitants and biochemistry of the explosive discharge mechanism of some little known Bombardier Beetles, Experientia 39:366–368, 1983.
  3. Blum, M.S., Chemical Defenses of Arthropods, Academic Press, New York, 1981.
  4. Crowson, R.A., The Biology of the Coleoptera, Academic Press, New York, 1981.
  5. Eisner, T., The protective role of the spray mechanism of the Bombardier Beetle, Brachynus ballustarius, J. Insect Physiology 2:215–220, 1958.
  6. Eisner, T., Chemical defense against predation in arthropods; in: Sondheimer, E., and Simeone, J.B. (Eds), Chemical Ecology, Academic Press, New York, 1970.
  7. Eisner, T. and Aneshansley, D.J., Spray aiming in Bombardier Beetles: jet deflection by the Coandă effect, Science 215:83–85, 1982.
  8. Eisner, T. and Aneshansley, D.J., Spray aiming in the Bombadier Beetle: photographic evidence, Proc. Nat. Acad. Sci. USA 96:9705–9709, 1999.
  9. Eisner, T., Aneshansley, D.J., Eisner, M., Attygalle, A.B., Alsop, D.W. and Meinwald, J., Spray mechanism of the most primitive Bombardier Beetle (Metrius contractus), J. Experimental Biology 203:1265–1275, 2000.
  10. Eisner, T., Attygalle, A.B., Eisner, M., Aneshansley, D.J. and Meinwald, J., Chemical defense of a primitive Australian Bombardier Beetle: Mystropomus regularis, Chemoecology 2:29–34, 1992.
  11. Eisner, T., Jones, T.H., Aneshansley, D.J., Tschinkel, W.R., Silbergleid, R.E. and Meinwald, J., Chemistry of defensive secretions of Bombardier Beetles (Brachanini, Metriini, Ozaenini, Paussini), J. Insect Physiology 23:1383–1386, 1977.
  12. Forsyth, D.J., The structure of the pygidial defence glands of Carabidae (Coleoptera), Transactions of the Zoological Society of London 32:249–309, 1972.
  13. Schildknecht, H. and Holoubek, K., Die bombardierkäfer und ihre explosionschemie, Angewandte Chemie 73(1):1–7, 1961.
  14. Schildknecht, H., Maschwitz, E. and Maschwitz, U., Die explosionschemie der bombardierkäfer: struktur und eigenschaften der brennkammerenzyme, J.Insect Physiology 16(4):749–789, 1970.
  15. Schnepf, E., Wenneis, W. and Schildknecht, H., On the defense substances of arthropods. The chemistry of the Bombadier Beetle (Coleoptera, Carabidae), IV. The fine structure of the defensive glands of Brachynus crepitans, Zeitschriftfèur Zellforschung und mikroskopische Anatomie 96:582–599, 1969.
  16. Erwin, T., A reclassification of Bombardier Beetles and a taxonomic revision of the North and Middle American species (Carabidae: Brachinida), Quaestiones Entomologicae 6:4–215, 1970.
  17. Dean, J., Aneshansley, D.J., Edgerton, H.E. and Eisner, T., Defensive spray of the Bombadier Beetle: a biological pulse jet, Science 248:1219–1221, 1990.
  18. Dean, J., Encounters between Bombardier Beetles and two species of toads (Bufo americanus, Bufo marinus): speed of spray capture does not determine success, J. Comp. Physiology 135:41–50, 1980.
  19. Nakatani H.S., de Oliveira N.G, Godinho O.E., Aleixo L.M. and Zinner K., Bombardier Beetle based biosensor, Biosensors and Bioelectronics 11:489–492, 1996.
  20. Anon., The amazing Bombardier Beetle!, Creation 12(1):29, 1990.
  21. Bombardier Beetle debate and poll: is this proof that evolution may be false?, 25 May 2001.
  22. Gish, D.T., Dinosaurs: Those Terrible Lizards, Creation Life Publishers, San Diego, 1977.
  23. Gish, D.T., Creation Scientists Answer Their Critics, Institute for Creation Research, El Cajon, 1993.
  24. Hitching, F., The Neck of the Giraffe, Ticknor and Fields, New York, 1982.
  25. Huse, S.M., The Collapse of Evolution, Baker Books, Grand Rapids, 1993.
  26. Kofahl, R.E., The Bombadier Beetle shoots back, Creation/Evolution 2(3):12–14, 1981.
  27. Rue, H.M., Bomby the Bombardier Beetle (third printing), Institute for Creation Research, El Cajon, 1993.
  28. Arthur, J., Creationism: bad science or immoral pseudoscience?, Skeptic 4(4):88–93, 1996.
  29. Isaak, M., Bombardier Beetles and the argument of design, The Talk Origins Archive, 24 April 2001.
  30. The Bombardier Beetle <http://www.ic.ucsc.edu/%7Eenvs24/Lecture11/sld043.htm> (example of coevolved predator/prey relationships).
  31. Weber, C.G., The Bombadier Beetle myth exploded, Creation/Evolution 2(1):1–5, 1981.
  32. Weber, C.G., Response to Dr Kofahl, Creation/Evolution 2(3):15–17, 1981.
  33. Behe, M.J., Darwin’s Black Box: The Biochemical Challenge to Evolution, Touchstone, New York, 1996.
  34. Snodgrass, R.E., Principles of Insect Morphology, McGraw-Hill, New York, 1935.
  35. Eisner, T. and Meinwald, J., Defensive secretions of arthropods. Insects, millepedes and some of their relatives discharge noxious secretions that repel their predators, Science 153:1341–1350, 1966.
  36. Dawkins, R., The Blind Watchmaker: Why the Evidence of Evolution Reveals a Universe Without Design, W.W. Norton & Co, New York, London, 1986.
